Self Centering Vise-SCV
1.Self Centring Precision Vise is suitable for 4 and 5 Axis usage, either in horizontal or vertical machining.
2.5 Axis Vise precision of its center repetiion position is ±0.01mm.
3.Using high quality cast iron FCD 60(GGG 60). Slideway has high frequence heat treatness at HRC45o or more to keep the accuracy and its long use life.
SELF CENTRING VISE
Unit/mm
| MODEL | A | B | C | D | E | F | G | H | I | I1 | I2 | J | J1 | K | K1 | K2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCV-60 | 59 | 60 | 18 | 60 | 25 | 143 | 120 | 13 | 0~50 | 38~85 | / | 17.5 | 12.5 | 12.5 | / | |
| SCV-100 | 100 | 101 | 22 | 80 | 40 | 275 | 240 | 20 | 0~90 | 70~160 | 134-222 | 35 | 31 | 18 | 18 | 4 |
| SCV-160 | 160 | 161 | 22 | 105 | 55 | 440 | 370 | 70 | 0~200 | 86~285 | / | 42.5 | 27.5 | 27.5 | / |
1.Self Centring Precision Vise is suitable for 4 and 5 Axis usage, either in horizontal or vertical machining.
2.Vise precision of its center repetiion position is ±0.01mm.
3.Using high quality cast iron FCD 60(GGG 60). Slideway has high frequence heat treatness at HRC45o or more to keep the accuracy and its long use life.
4.Vise hard jaw material is full Steal and heat treatness at HRC 55o or more. Thanks for its good design to use both sides of jaw since it is exchangeable.
5.Special design for the Self Centring Precision Vise to prevent work piece from bending during clamping and machining. Thus, it has the best solution in clamping the work piece.
